Pioneer® Diamante Pro Series 18,000 BTU 19 SEER2 Ductless Mini-Split Air Conditioner Inverter+ Heat Pump Full Set 230V with 16 Ft. Kit
SKU: WYT018GLFI19RL
Overview
Summary
- High Efficiency Diamante Pro Ductless Mini Split Heat Pump System
- Cooling capacity: 18,000 BTU/H with 19 SEER2 / 9.4 EER2 efficiency
- Heating capacity: 19,000 BTU/H with 8.5 HSPF2 / 3.21 COP2 efficiency
- Voltage: 208~230V, 60Hz, 1Ph
- High Wall Mounted Air Conditioning & Heating System
- Variable Speed DC Inverter Operation Mode
- Low Ambient Unit (-13°F)
- AHRI Estimated Annual Operating Costs:
- Cooling: $125.00
- Heating: $402.00
Refrigerant
R410A Pre-Charged Outdoor Unit, accommodating refrigerant line lengths up to 25 ft. per circuit.
IMPORTANT NOTE
The copper tubing is included in the outdoor unit cardboard box and the communication wiring kit is included in the indoor unit cardboard box. This product set is comprised of 2 cartons only.
What's Included
- Indoor Unit
- Outdoor Unit
- Wireless Remote Control (with wall holder and batteries)
- 16 Ft. Copper Lines
- 16 Ft. Electrical Wire
- 10 Ft. Drain for indoor/outdoor
- Wall Passage Sleeve
- Putty for Wall Hole
- Leak Guard Sealer
- Wrapping Tape
- Installation Manual
- User’s Manual
Our Guarantee
- 5 years Warranty for Parts
- 5 years Warranty for Compressor
Features
- Dual Swing
- Dual Drainage
- Low Noise
- High Efficiency
Notes: See comparison table with WYS series
Technical Information
Performance Data
- Power Supply: 208~230V, 60Hz, 1Ph
- Cooling Rated Capacity: 18,000 BTU/h
- Cooling Capacity Range: 5,400~19,800 BTU/h
- Cooling SEER2: 19.0 BTU/W.h
- Cooling EER2: 9.4 BTU/W.h
- Heating Rated Capacity: 19,600 BTU/h
- Heating Capacity Range: 5,880~21,560 BTU/h
- Heating HSPF2 (Region IV/V): 8.5 / 7.0 BTU/W.h
- Heating C.O.P.2 (47°F/5°F): 3.21 / 1.75 W/W
- Refrigerant Type: R410A/44
- Suitable Area: 350~650 Sq.F
Indoor Unit Data
- Part Number: WT018GLFI19HLE
- Air Flow (Hi/Med/Lo): 606 / 465 / 429 CFM
- Sound Level (Hi/Med/Lo): 45 / 40 / 35 dB(A)
- Net Dimensions (WDH): 39-3/4 x 8-5/8 x 12-3/8 Inches
- Carton Dimensions (WDH): 43-1/8 x 11-7/8 x 15-3/8 Inches
- Net / Gross Weight: 28.7 / 35.3 lbs
Outdoor Unit Data
-
Part Number: YN018GLFI19RPE
- Breaker Needed: 20A (double-pole)
- Sound Level: 52 dB(A)
- Net Dimensions (WDH): 30-3/4 x 13-3/4 x 23-7/8 Inches
- Carton Dimensions (WDH): 35-3/8 x 15-7/8 x 25-3/4 Inches
- Net / Gross Weight: 73.8 / 84.9 lbs
Manuals & Documents
Free Shipping For All Orders Over $49
For a Limited Time we offer free shipping on All Orders Above $49 by Standard Ground or delivered by Freight (LTL) to the 48 contiguous states. Free shipping offer does not apply to Alaska, Hawaii, or any international destination. Free shipping eligibility is noted on the product page, above the price.
Click here for information on Returns and Refunds
Shipping Details
We only ship to the 48 contiguous United States. No shipments to APO/FPO addresses, AK, HI, PR or other US Territories. No international shipments. Due to the size and the weight of our equipment, we can only utilize well known freight companies for shipping. Each shipment will be palletized, strapped down and wrapped in stretch film to protect against damages during transit.
Upon arrival you may ask the driver to break down the palette into individual cartons to unload the goods from the truck easily. We generally include Lift Gate service. This will arrive as curb side delivery. Trucker will unload the goods from the truck to ground level. If you must have inside delivery service, there will be an additional charge which needs to be paid separately and coordinated with the freight company. We also allow free pickup from our main distribution warehouse, located in Miami area. Equipment we sell is not suitable for express or courier shipping because of their weight as well as high risk of damages.
Due to higher than expected order volume and busy sales season, larger orders may take an extra 3-5 days to be prepared for shipment. We are working around-the-clock to ship out all orders in a timely manner, and will communicate with you if there are any unexpected delays or questions.
We prepare each shipment within 72 hours after the receipt of payment (only during weekdays). Trucking companies usually pick up same day or a day after we call them that the shipment is ready. The transit may take any time between 5 to 8 business days and in rare cases up to 12 days.
We will provide tracking information after shipment. Please contact us in case of any shipment delays. CHECK YOUR INFORMATION CAREFULLY TO SUBMIT THE CORRECT DELIVERY ADDRESS, UPDATED EMAIL AND A VALID PHONE NUMBER with your order. Someone must be present to receive the cargo at the time of delivery. Delivery company will call your phone number to setup a delivery appointment for residential deliveries. If your phone number is not valid, the cargo can not be delivered and will be returned at your expense within 3 days of arrival. If the delivery is refused or can not be delivered, it will be handled as returned merchandise.
Upon arrival, count all cartons and compare with the number stated on the delivery receipt before signing. Open the cartons and inspect the goods carefully for any damages. All products have been inspected under strict ISO regulated facilities and leave our warehouse in perfect condition. Report any shipping damages to the freight carrier on the delivery receipt and file a claim. Also contact us with the description of damages and pictures, etc. Although rare, certain freight damages can occur and we are here to help.
We carry all necessary replacement and service parts and components in large quantities and make them available during and after the warranty period.
You may also like
More from Ductless Mini Split Heat Pump
Recently viewed
QUESTIONS & ANSWERS
Ask a Question-
What size electric wire do I need on the 18000 BTU unit? And does it come with the unit? Does the flex conduit come with the unit?
This would take a 20A double-pole breaker. The corresponding wire would be 12 AWG, with 2 hots and a ground, no neutral. Electrical hookup is not included but we do offer a Disconnect Box and a Flexible Conduit.
-
Do you have just A/C no heat units on sale
All of our systems are heat pumps meaning heating and cooling. We do not carry AC only units, but you can disable the heat function if not needed.
-
What size amperage should the breaker be ?
This would take a 15A double pole breaker with 14 AWG wire.
-
How do I get a 25 ft line set
The Diamante series comes pre-packed with a 16 ft lineset which cannot be modified during purchase. If you need longer, it would require purchasing either the WYS series, or a longer lineset here.
-
will unit still heat at 0 degrees
This unit will heat down to -13°F outside temperatures.
Customer Reviews
4.8 Based on 57 Reviews
Customer Photos
- Reviews
- Questions
Filter Reviews:
- unit
- pioneer
- shipping
- problems
- system
- friend
- mode
- parts
- installation
- size
GG
10/06/2023
Greg G.
United States
I recommend this product
Diamante Pro 18k btu review.
As ductless heat pump owners for 9 years ( another brand ) we knew the awesome advantage of going ductless. Therefore, when it was time to replace one ( of two ) we knew what to look for. With the dizzying amount of brands ( besides Mitsu & Daiken ) it took a bit of homework an reading reviews prior to selecting one. We chose Pioneer based on not only a great price, but the support ( parts, warranty, web info ) is outstanding. Buying direct from Pioneer is not for everyone as you still have to have it installed and most HVAC contractors will only install units that they sell. So it takes a bit of hunting to find a licensed contractor that will install third party units. That being said, they're out there. We probably saved $3000-5000 buying direct and paying $1200 to have it installed. And it is larger and more efficient than our previous unit. Cools quietly and we're expecting it to heat ( coming up ) just as good. Obvious question is " would I buy another Pioneer" ? ........absolutely
A
08/17/2023
Anonymous
United States
I recommend this product
Wonderful so far
Easy install, had hvac guy come hook up the refrigerant lines and vacuum them out, took a couple hours for that. The unit is super quiet and efficient. It cools off our 600 square foot living area and kitchen no problem and the rest of the rooms and hallway are cooler too, requiring less energy to condition those spaces.
BW
08/17/2023
Brian W.
United States
I recommend this product
Best purchase I've made
I installed this unit to help with my current system and it was the best decision I made. This unit was super easy to install. The indoor unit was installed in the living room and I was concerned that the blower would make watching television difficult, but this thing is extremely quiet. I am glad I purchased this unit. The outdoor unit is sitting close to a window and you can not hear it at all, even if your standing next to m it outside. The follow me mode on the remote helps keep the temperature set to where your sitting in the room. I have only had it installed for a day and so far I'm happy with this purchase.
TJ
03/07/2022
Thomas J.
Irwin, Pennsylvania, United States
Great Unit
I actually ordered my Pioneer 18K unit at Home Depot. It took a week for it to arrive at the store, which was great. I took my time reading all the installation material and started slowly performing the installation in my garage. Everything went great without any problems. I did need to shorten the copper lines. I used an eccentric flaring tool as it produces a very smooth flare with out smearing .I used Nylog on all the flares. The system vacuumed down as required and no leaks were detected. Released the refrigerant and started the unit with the remote. It worked perfectly in both the heat and cool modes. I also purchased the optional wi-fi module. It was a little troublesome to get operational. I tried connecting multiple times using the onscreen prompts without any luck (Smart Life app) I then downloaded the Pioneer Airlink app. It also proved troublesome, but after approx 5 attempts, the connection/communications finally happened using the Airlink app. It is great that I will be able to control the unit remotely so I can turn it on before I actually go out to the garage to do some work. Would buy another Pioneer unit if the need for another arises.
DB
06/28/2021
Dwayne B.
San Antonio, Texas, United States
I have been working with Erik on my damaged delivery. He has done a great job.
Received but was damaged in shipping. Waiting for replacement.
